ECHO
SRM-520ES
SRM-520ES
The ECHO SRM-520ES/U is designed to tackle the largest scale commercial jobs. That's why it features a huge 50.2cc engine, a heavy duty air filter and an advanced vibration reduction system. Whether you're working with a trimmer head or blade, you can depend on its power to get through the job with ease.
The ECHO SRM-520ES/U features a super anti-vibration feature that utilises a 4-point mounting system ensuring low vibrations, so you can power through jobs in comfort.
Featuring ECHO's patented ES-start technology for easy starting every time and a heavy duty air filter to protect against dust and debris. Every feature has been carefully crafted to reduce downtime and get you from one job to the next, hassle-free.
Specification
| Engine displacement (cc) | 50.2 |
|---|---|
| Output (kW) | 2.16 |
| Dry Weight (kg) | 9.0 |
| Fuel Tank Capacity (ml) | 690 |
| Start Assist System | ES-start |
| Drive shaft diameter (mm) | 8.0 |
| Main pipe diameter (mm) | 28.0 |
| Gear reduction ratio | 1.33 |
| Standardised Nylon Head | DS-5 M10L |
| Standardised Metal Blade | 3-cutter |
| Vibration Left handle/Right handle (m/s) Metal Blade | 3.4 / 3.4 |
| Vibration Left handle/Right handle (m/s) Nylon head | 3.0 / 2.7 |
| Sound power level (dB(A)) Blade/Nylon head | 113.2 / 111.6 |
| Sound pressure level (dB(A)) Blade/Nylon head | 98.2 / 97.6 |
| CO² (g/kW・h) 1 | 825 |
1 This CO² measurement results from testing a (parent) engine representative of the engine type (engine family) over a fixed test cycle under laboratory conditions and does not imply or express any guarantee of the performance of a particular engine.
Features

![]()

Read about them here
X-Series
X-Series means ECHO's best-in-class products. More power, lighter weight and performance that will noticeably increase your productivity. Designed for professionals who demand the best and highest quality tools.
X-Series engines make this line-up exceptional. They offer a revolutionary combination to get jobs done faster with less fatigue.
Read about X-Series here
